Trapezodial Roof Mount SN-TMR Series

Trapezodial Metal Roof Mounting System SN-TMR Series

Snergytec's Trapezoidal Metal Roof Solar PV Mounting System is applied to Trapezodial roof sheet. It can use with rail or without rail for the whole solar system. The EPDM contained between clamp and roof help to prevent water dropping. Compatible with different types of solar modules, advanced design with Al6005T5 high corrosion resistance material, it’s easy to install and save costs.

Technical Date

• Location: pitched roof

• Max wind speed: 60m/s

• Snow load: 1.6 kN/m2

• Building height: Up to 20 m

• PV modules: Framed, unframed

• Module orientation: upright, landscape

• Standards: Eurocode 1, AS/Z1170.2,JIS 8955,UL2703

• Material: Aluminium 6005T5 SS304

• Color: mill / natural / black

• Warranty: 15 years

• Duration: more than 20 years

• Enables simple, fast and cost-effective installation

• Al6005-T5. High class anodized aluminium

• Waterproof EPDM rubber intergrated

• Rail or without rail design
